※Medal clamp is sold separately.
| Medal Clamp (Center fixing type) |
 |
1EA | For holding materials with various shapes in place. |
| Pin(3Ø) (CP-172) |
 |
6EA | To secure materials with irregular shapes. |
The clamp that holds the medal clamp is a step type. Set the medal clamp to the step type clamp to match the size and thickness of the material. To secure the material (tighten the gap), lift the clamp bar then turn the clamping knob to the right.
Marks may be left on the material if fastened tightly.
- Insert the clamp fixing pins into the holes to secure the medal clamp.
- Attach the medal clamp to the clamp fixing pins.
- Use the clamping pins to firmly hold materials with irregular shapes in place. To secure the clamping pins to the clamp, simply insert the pins into the pin holes then fasten them.
- Turn the clamping knob clockwise to secure the material.
